Spraying Device:
◆ The oil dispersant sprayer is mainly used to spray oil dispersant for removing spilled oil from water surface,shores,beaches,rocky areas and building.it can be used to spray clean water or detergent to clean oil booms or other objects,too.
Features of Spraying Device:
◆ Two models are available.Model PS 160 is a ship-sized spraying device consisting of a pump,suction arm and handheld spray gun,moving together with the vessel,used for eliminating large area of spilled oil.Model PS 40 is a portable one,mounted on a small cart,easy to move and operate,particularly suitable for using in those areas inaccessible by a ship or a boat.
TECHNICAL DATA
| Model | Max.flow rate(T/H) | Working pressure(Mpa) | Suction head | Max.spraying distance | Power(KW) | weight(kg) | External dimensions(cm) |
| PS40 | 2.4 | 1~2 | ≤3 | 12 | 3 | 70 | 70×65×60 |
| Model | Max.flow rate(T/H) | Working pressure(Mpa) | Length of suction arm | Number of spray heads | Suction head | Weight(kg) | External dimensions of pump station(cm) | Power(KW) | Spray gun | Max.spraying distance of spray gun(m) | Max.flow rate of spray gun |
| PS160 | 10 | 0.3~0.5 | 5.3 | 6 | ≤3 | 400 | 75×50×60 | 4.5 | 2 | 10 | 1.8 |
Qingdao Xinjinghua environmental Protection Technology Co., Ltd. is a professional manufacturer of oil spill response equipment and pollution remove products. Our company was founded in 2003.
